Filling and Packing Room

Configured for wet packaging, this room comprises packaging equipment ranging from rotary filling and sealing machines to mobile weight fillers and vacuum chamber sealer, amongst others.

Equipment

---

Rotary Filling and Sealing Machine for Pre-Made Pouches



Specifications

• Features 10 stations which include loading of pouches, filling of liquids and solids, removal of trapped air, and and gas flushing and sealing.
• Pack speed: 15–30 bag per min
• Product type: Solid &/or liquid
• Pouch types:
  • Pre-made pouch
  • Standup pouch
• Pouch sizes:
  • 100 – 240 mm width
  • 150 – 350 mm length
• Pouch Material:
  • PP/nylon laminate
  • Metalised laminate
  • Aluminium laminate
  • Packaging material suitable for retort

---

Mobile Weight Filler



Specifications

• Filling weight per pouch/bag: 100 g – 5 kg
• Filling temperature of the product: 10^oC to more than 90^oC

---

Vacuum Chamber Sealer



Specifications

• 1 sealing bar
• Double seam sealing (seal width 2 x 3 mm)
• Usable area : 440 x 470 mm
